RCR24SS High EMI Receiver 3-Ch w/10A Relays
$146.95
Model:
RCR24SS3R
Description:
The RCR24SS Series remote control receivers are designed to provide a quick and cost effective solution for a variety of wireless remote control relay applications. The receiver includes an external antenna, decoder and three 10-Amp on-board relays. The receiver utilizes spread spectrum technology and offers excellent electromagnetic interference (EMI) tolerance, often found in AC and DC motor applications. Units are designed to work with Applied Wireless 2400 MHz transmitters. These products will not interfere with or be affected by Wifi systems. This is a learning receiver, and can learn up to 60 different transmitters.
Includes:
Receiver, 3-dBi Rubber Duck Antenna (800253A-3)
Description
FEATURES
High EMI Tolerance
Three 10-Amp SPDT On-Board Relays
Long Range – 500 ft1 And More
Integrated Code-Learning Decoder
Can Learn up to 60 Transmitter IDs
4 Billion+ Unique Transmitter IDs
Momentary, Latched, or Toggle Operation
12-24 Volt DC or AC Operation
LED Output Activation Indicators
Made in USA
TYPICAL APPLICATION
Remote Control
Industrial ON/OFF Applications
Motor Control
Solenoid Control
Lighting Control
Access Control
PLC Activation
Additional information
Weight | 1 lbs |
---|---|
Dimensions | 5.5 × 4 × 1.5 in |
